Описание на продукта
Параметри на продукта
Производител
Uniview
Параметри на продукта
Производител
Uniview
Описание на продукта
Optics:
Day/night functionality
3D DNR (Digital Noise Reduction)
SmartIR, up to 30m (98 ft) IR distance
Built-in motorized lens for remote zoom and autofocus(-Z model support)
Compression:
H. 264 High Profile
Triple streams
ROI (Region of Interest)
9:16 corridor mode
Customized OSD
Network:
ONVIF Conformance
Structure:
Built-in PoE splitter that outputs DC 12V
Wide voltage range of ±25%
IK10 vandal resistant
IP66
Camera:
Sensor- 1/3", 1.3 megapixel, progressive scanCMOS
Shutter- Auto/Manual, 1/6~1/8000 s
Lens- 2.8 ~12 mm, F1.4
Zoom/Focus- Motor drive
Angle of View (H)- 90° (wide)~28° (tele)
Min. Illumination- Colour: 0.03 Lux (F1.4, 50IRE)
Black & White- 0.01Lux (F1.4, 50IRE)
Day/Night- IR-cut filter with auto switch (ICR)
S/N- >50dB
IR- Smart-IR , up to 30m (98 ft) IR range
Video:
Max. Resolution- 1280 × 960
Video Compression- H. 264, MJPEG
Frame Rate- 960P (1280*960) 30 fps; 720P (1280*720) 30 fps; D1 (720*576) 25 fps
9:16 Corridor Mode- Supported
ROI(Region of Interest)- Supported
Video Streaming Triple:
OSD- Up to 8 OSDs
Privacy Mask- Up to 8 areas
Audio:
Audio Compression- G. 711
Two-way audio- Supported
Storage:
Edge Storage- Micro SD, up to 64 GB
Network:
Protocols- L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, Qos, NTP, FTP, HTTP, SNMP, SIP
Compatible Integration- ONVIF, IMOS, API
Interface:
Audio I/O:
3.5 mm audio interface
Input: impedance 35 k; amplitude 2 V [p-p]
Output: impedance 600 ; amplitude 2 V [p-p]
Alarm I/O- 2 / 1
Serial Port- 1 RS485
Network- 10M/100M Base-TX Ethernet
Video Output- 1 BNC, impedance 75 ; amplitude 1 V [p-p]
General:
Power- 12 V DC, or PoE (IEEE802.3 af)
Power consumption- 4.5W (8.7W with IR on)
Dimensions (Ø x H)- Φ149 x 105 mm (Ø5.9 x 4.1)
Weight- 0.75 kg (1.7 lb)
Working Environment- -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)
Vandal Resistant- IK10
Ingress Protection- IP66
Day/night functionality
3D DNR (Digital Noise Reduction)
SmartIR, up to 30m (98 ft) IR distance
Built-in motorized lens for remote zoom and autofocus(-Z model support)
Compression:
H. 264 High Profile
Triple streams
ROI (Region of Interest)
9:16 corridor mode
Customized OSD
Network:
ONVIF Conformance
Structure:
Built-in PoE splitter that outputs DC 12V
Wide voltage range of ±25%
IK10 vandal resistant
IP66
Camera:
Sensor- 1/3", 1.3 megapixel, progressive scanCMOS
Shutter- Auto/Manual, 1/6~1/8000 s
Lens- 2.8 ~12 mm, F1.4
Zoom/Focus- Motor drive
Angle of View (H)- 90° (wide)~28° (tele)
Min. Illumination- Colour: 0.03 Lux (F1.4, 50IRE)
Black & White- 0.01Lux (F1.4, 50IRE)
Day/Night- IR-cut filter with auto switch (ICR)
S/N- >50dB
IR- Smart-IR , up to 30m (98 ft) IR range
Video:
Max. Resolution- 1280 × 960
Video Compression- H. 264, MJPEG
Frame Rate- 960P (1280*960) 30 fps; 720P (1280*720) 30 fps; D1 (720*576) 25 fps
9:16 Corridor Mode- Supported
ROI(Region of Interest)- Supported
Video Streaming Triple:
OSD- Up to 8 OSDs
Privacy Mask- Up to 8 areas
Audio:
Audio Compression- G. 711
Two-way audio- Supported
Storage:
Edge Storage- Micro SD, up to 64 GB
Network:
Protocols- L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, Qos, NTP, FTP, HTTP, SNMP, SIP
Compatible Integration- ONVIF, IMOS, API
Interface:
Audio I/O:
3.5 mm audio interface
Input: impedance 35 k; amplitude 2 V [p-p]
Output: impedance 600 ; amplitude 2 V [p-p]
Alarm I/O- 2 / 1
Serial Port- 1 RS485
Network- 10M/100M Base-TX Ethernet
Video Output- 1 BNC, impedance 75 ; amplitude 1 V [p-p]
General:
Power- 12 V DC, or PoE (IEEE802.3 af)
Power consumption- 4.5W (8.7W with IR on)
Dimensions (Ø x H)- Φ149 x 105 mm (Ø5.9 x 4.1)
Weight- 0.75 kg (1.7 lb)
Working Environment- -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)
Vandal Resistant- IK10
Ingress Protection- IP66
