Camera

Image Sensor
1/4 Progressive scan CMOS

Effective Pixels
1280(H)x720(V)

Scanning System
Progressive

Electronic Shutter Speed
Auto/Manual,  1/3s~1/30000s

Min.  Illumination
0.01lux/F1.8（color）

S/N Ratio
More than 50dB

Video Output
N/A

Camera Features

Max.  LEDs Length
10m

Day/Night
Auto(ICR) / Color / B/W

Backlight Compensation
BLC / HLC / DWDR

White Balance
Auto/Manual

Gain Control
Auto/Manual

Noise Reduction
3D

Lens

Focal Length
3.6mm

Max Aperture
F1.8

Focus Control
Manual

Angle of View
H:62°

Lens Type
Fixed Lens

Mount Type
Board-in Type

PT

Pan/ Tilt Range
Pan: 0°~355°; Tilt: 0°~90°

Preset Speed
100°/s

Preset
25

Tour
8

Video

Compression
H. 264/H. 264B/MJPEG

Resolution
720P(1280x720)/D1/CIF

Frame Rate
Main Stream
720P(1~25/30fps)

Sub Stream
D1/CIF(1 ~ 25/30fps)

Bit Rate
H. 264: 8Kbps～8192Kbps

Audio

Compression
G. 711a;G. 711Mu;AAC

Interface
Built-in Mic & Speaker

Network

Ethernet
RJ-45 (10/100Base-T)

Wi-Fi
Wi-Fi(IEEE802.11b/g/n) 50m(open field)

Protocol
IPv4/IPv6,  HTTP,  TCP/IP,  UDP,  UPnP,  ICMP,  IGMP,  RTSP,  RTP,  SMTP,  NTP,  DHCP,  DNS, FTP,  QoS,

Compatibility
ONVIF CGI

Max.  User Access
10 users

Smart Phone
iPhone,  iPad,  Android,  Windows Phone

Auxiliary Interface

Memory Slot
Micro SD,  up to 64GB

RS485
N/A

Alarm
N/A

PIR Sensor Range
N/A

General

Power Supply
DC 5V2A

Power Consumption
