· 1/2.8 2Megapixel progressive scan STARVISTM CMOS
· H. 265&H. 264 triple-stream encoding
· 50/60fps@1080P(1920×1080)
· Smart Detection supported
· WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
· Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
· 3.6mm fixed lens (6mm optional)
· Max. IR LEDs Length 40m
· Micro SD Memory, IP67, PoE

Technical Specification

Camera
Image Sensor: 1/2.8 2Megapixel progressive scan CMOS
Effective Pixels: 1920(H) x 1080(V)
RAM/ROM: 256MB/32MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3(4)~1/100000s
Minimum: Illumination
0.007Lux/F1.6( Color, 1/3s, 30IRE)
0.06Lux/F1.6( Color, 1/30s, 30IRE)
0Lux/F1.6(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 40m (131ft)
IR On/Off: Control Auto/ Manual
IR: LEDs 2

Lens
Lens Type: Fixed
Mount Type: Board-in
Focal Length: 3.6mm (6mm optional)
Max. Aperture: F1.6 (F1.6)
Angle of View: H: 87° (52°), V: 46° (30°)
Optical Zoom: N/A
Focus Control: Fixed
Close Focus Distance: 1.2m(2.4m)

DORI Distance:
Lens DetectObserveRecognize Identify
3.6 mm 55m(180ft) 22m(72ft) 11m(36ft) 6m(20ft)
6.0 mm 83m(289ft) 33m(108ft) 17m(56ft) 8m(26ft)

Pan/Tilt/Rotation
Pan/Tilt/Rotation Range: Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚

Intelligence
IVS: Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions: Face Detection

Video
Compression: H. 265+/H. 265/H. 264+/H. 264
Streaming Capability: 3 Streams

Resolution
1080P(1920x1080)/1.3M(1280x960)/
720P(1280×720)/D1(704×576/704×480 )/
VGA(640×480)/CIF(352×288/352×240)

Frame Rate
Main Stream: 1080P (1~50/60fps)
Sub Stream: D1(1~50/60fps)
Third Stream: 1080P(1~25/30fps)

Bit Rate Control: CBR/VBR
Bit Rate: H. 264: 24K ~ 10240Kbps, H. 265: 14K ~ 9984Kbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / WDR(120dB)
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detetion: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Electronic Image Stabilization (EIS) N/A
Smart IR: Support
Defog: N/A
Digital Zoom: 16x
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)

Audio
Compression N/A

Network
Ethernet: RJ-45 (10/100Base-T)
Protocol:
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
Interoperability: ONVIF, PSIA, CGI
Streaming Method: Unicast / Multicast
Max. User Access: 10 Users /20 Users
Edge Storage: NAS, Local PC for instant recording, Mirco SD card 128GB
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: Smart PSS, DSS, Easy4ip
Smart Phone: IOS, Android

Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B

Electrical
Power Supply: DC12V, PoE (802.3af)(Class 0)
Power Consumption:

Продукт известен още и като IPC HFW 4231 E SE 0360 B, IPCHFW4231ESE0360B, IPC HFW4231E SE 0360B, IPC HFW4231E-SE-0360B, IPC-HFW4231E-SE-0360 B
