Camera

Image Sensor
1/3" Progressive Scan CMOS Sensor

Resolution
4MP

Effective Pixels
2560(H)*1440(V)

Compression
H. 264/H. 264+/H. 265/H. 265+/JPEG/AVI/MJPEG

Audio Compression
G711A/U, AAC

TV System
PAL/NTSC

Electronic Shutter Time
Auto: 1/3-1/100000Sec

Minimun Illumination
Color: 0.03 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR

S/N Ratio
60dB

Scanning System
Progressive

Video Output
Network

Reset Button
Optional

Lens

Focal Length & FOV
2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122°

3.6 mm, horizontal FOV 81°, vertical FOV 41°, diagonal FOV 96°

6 mm, horizontal FOV 50°, vertical FOV 27°, diagonal FOV 59°

Lens Type
Fixed focal lens, 2.8, 3.6, and 6 mm optional

Focus Control
Fixed

Aperture
F1.6

Pixels
4MP

Night Vision

Infrared LED
42 x 2PCS

Infrared Distance
25M

IR Status
Auto Control

IR Power On
Smart, Manual & Timed mode

Network

Ethernet
RJ-45 (10/100Base-T)

Wireless
N/A

Protocol
TCP/IP, IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP,   RTCP , PPPoE, NTP, SMTP, UDP, Qos, 802.1x

ONVIF
Support ONVIF 19.12(Profile S/T/G)

P2P
YES

POE
Internal, Support IEEE 802.3af

Video Delay
0.3S (Within the Lan)

Main Stream 1
2688*1512@25fps

Main Stream 2
2560*1440@30fps

Main Stream 3
1920*1080@30fps

1280*720@30fps

Sub Stream 1
1280*720@30fps

Sub Stream 2
720*480@30fps

Sub Stream 3
N/A

Tri Stream
N/A

IE Brower
IE8-11, Google Chrome, Firefox , Mac Safari

Smart Phone
iPhone, Android

AI Function

Intelligent Analysis
Intrusion Detetion, motion detection based on human detection

Camera Features

Day/Night
Color/ B&W (IR-CUT )

Image Config
Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control), Video Tampering, HLC, Distortion

Full Color
N/A

Corridor Pattern
Support

Defog  Mode
Support

ROI
Support

BLC
Support

WDR
DWDR

Motion Detection
Support(support enable the detection based on human movement only)

Privacy  Masking
3 Rectangular Zone

Recording Mode
NVR/CMS/Web

Language
Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Nederlands, Czech, Vietnamese

Interface

Audio
Optional 1 Built-in MIC

Alarm
N/A

SD Card Slot
Optional Internal, Support Max 512GB

RS485
N/A

General

Housing
Metal , IP67

Anti-cut Bracket
NO

IR Cut Filter
YES

Operation Temperature
-20℃ ~ +60℃ RH95% Max

Storage Temperature
-20℃ ~ +60℃ RH95% Max

Power Source
DC12V±10%, 700mA

Dimension
70(W) x 67.5(H) x 169(L)mm

Weight
600g
