Optics

- Day/night functionality

- Smart IR , up to 30 m (98 ft) IR distance

- Optical glass window with higher light transmittance

- IR anti-reflection window to increase the infrared transmittance

- 3D DNR (Digital Noise Reduction)

Compression

- H. 265

- Triple streams

- 9:16 corridor format

Network

- ONVIF Conformance

Structure

- Wide temperature range: -35°C to 60°C (-31°F to 140°F)

- Wide voltage range of ±25%

- IP66

Sensor- 1/3", 4.0 megapixel, progressive scan, CMOS

Lens- [email protected] / Angle of view(H): 87°

Shutter- Auto/Manual, 1/6~1/8000 s

Min. Illumination- Colour: 0.02 Lux (F1.8, AGC ON) 0 Lux with IR on

Day/Night- IR-cut filter with auto switch (ICR)

IR Range- Up to 30m (98 ft) IR range

S/N- >55dB

WDR- 120dB

Noise Reduction- 2D/3D

Video:

Max. Resolution- 2592×1520

Video Compression- H. 265/H. 264/MJPEG

Frame Rate:
4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps
3MP (2048×1520): Max. 30 fps; 1080P (1920×1080): Max. 30 fps

Video Streaming- Triple

9:16 Corridor Mode- Supported

ROI- Supported

OSD- Up to 8 OSDs

Motion Detection- Up to 2 areas

Privacy Mask- Up to 4 areas

Network:

Protocols:
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SNMP, SIP, QoS

Compatible Integration- ONVIF, API

Interface:

Network- 1 RJ45 10M/100M Base-TX Ethernet

General

Power- 12 V DC, or PoE (IEEE802.3 af)

Power consumption: Max 6.4 W

Dimensions (L × W × H)- 157.3 × 62.4 ×63 mm (6.2 × 2.5 × 2.5)

Weight- 0.45 kg (0.99 lb)

Working Environment- -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing)

Ingress Protection- IP66
