Optics

Day/night functionality

Optical glass window with higher light transmittance

IR anti-reflection window to increase the infrared transmittance

Up to 30 m (98 ft) IR distance

3D noise reduction

Compression

H. 264/MJPEG

Triple streams

Network

ONVIF Conformance

Structure

Support PoE power supply (optional)

Wide temperature range: -35C to 60C (-31F to 140F)

Wide voltage range of 25%

4 KV surge protection designed for network interface

IP67

Camera:

Sensor- 1/3", 1.3megapixel, progressive scan, CMOS

Lens- [email protected]

Angle of View(H)- 105.2

Shutter- Auto/Manual, 1/6~1/100000 s

Min. Illumination- Colour: 0.02 Lux (F1.8, AGC ON) 0 Lux with IR

IR- 30m (98ft) IR range

Day/Night- IR-cut filter with auto switch (ICR)

WDR- Digital

AWB(Auto white balance)- Auto/manual

Gain Control- Auto/manual

Noise Reduction 2D/3D

Video:

Max. Resolution- 1280960

Video Compression- H. 264/MJPEG

Frame Rate- 960P (1280*960): Max. 30 fps; 720P (1280*720): Max. 10 fps;
960P (1280*960): Max. 25 fps; 720P (1280*720): Max. 15 fps; D1 (720*576): Max. 6 fps

Video Streaming Triple

Evaluative Metering- Supported

OSD- Up to 8 OSDs

Motion Detection- Up to 2 areas

Privacy Mask- Up to 4 areas

Network:
Protocols- IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP, HTTP
Compatible Integration- ONVIF

Interface:
Network- 10M/100M Base-TX Ethernet

General:

Power- 12 V DC, or PoE (IEEE802.3 af)

Power consumption- 3.5 W (5.5W with IR on)

Dimensions (Ø x H)- Φ126 x 94 mm (Ø5.0 x 3.7)

Weight- 0.33 kg (0.73lb)

Working Environment- -35C ~ +60C (-31F ~ 140F), Humidity 90% RH(non-condensing)

Ingress Protection- IP67
